18 Construction Specially moulded elastomer body combined with steel pressure plate and outer plate, integrated levelling system, 4 sizes Properties • Vibration isolation • Structure-borne sound insulation • Shock absorption (even at high horizontal forces) • Anchor-free installation • Load range 30 kN – 100 kN • Natural frequency vertical (stat.) 12 Hz – 20 Hz Application Horizontally operating equipment, such as injection moulding machines / presses (installed above ground-floor level) Materials • Elastomer body made from nitrile rubber NBR (90 SH A) with high elasticity, oil-resistant and non-ageing • Outer plate made of ductile cast iron or steel, powder coated yellow • Steel pressure plate • Screw ISO 8676 (DIN 961), galvanised Levelling Levelling with fine thread screw, levelling range max. 30 mm Delivery contents Support element with levelling screw LMP Series Dimension table Dimensions in mm D H 0 G L Machine base thickness (max.) Ni Element Weight kg Load (max.) kN LMP 16-90 165 59 M20x1.5 120 40 28 4.7 30.0 LMP 19-90 190 62 M20x1.5 120 40 30 5.9 50.0 LMP 24-90 240 64 M30x2 120 30 30 9.3 75.0 LMP 30-90 300 74 M30x2 120 30 30 18.8 100.0 D G H 0 Ni L LMP Series
