Page 8 | 1.1 Operating with Handles and Knobs GN 75.6 Mushroom Shaped Knobs Stainless Steel, Hygienic Design 3 Type D With internal thread E With threaded stud 1 d 1 2 d 3 (d 2 ) 3 Type 4 Finish 5 Material (Sealing ring) 1 2 3 4 5 GN75.6-25-M6-E-MT-H How to order 1 2 2 d 1 d 2 Type D d 3 Type E d 4 d 5 h Length l t min. 20 M 5 M 5 14 14,8 24 10 7 25 M 6 M 6 16 16,8 29 12 9 32 M 8 M 8 18 18,8 37 14 12 Information Mushroom shaped knobs GN 75.6 are intended for use in hygienic areas. The sealed mounting surface enables mounting without dead spaces; the impervious geometry in combination with the high quality finish prevents the accumulation of dirt and facilitates cleaning. They have a compact and timeless design. Specification 4 5 • Stainless steel AISI 316L - Matte finish (Ra < 0.8 μm) MT - Polished finish (Ra < 0.8 μm) PL • Sealing ring - H-NBR H Temperature resistant -25 °C to +150 °C - EPDM E Temperature resistant -40 °C to +120 °C - Blue - Hardness 85 ±5 Shore A - FDA compliant • Elastomer Characteristics Page 38 • Stainless Steel Characteristics Page 39 • RoHS • Sealing Rings GN 7600 Page 36 Accessory • with FKM sealing ring (Fluorine rubber) F On request
